Product Details:
Place of Origin: Jiangsu, China
Brand Name: Nanyang
Certification: As per customer request
Payment & Shipping Terms:
Price: CN¥3,020,391.67/sets 1-1 sets
Packaging Details: Sea worthy packing
Supply Ability: 200 Set/Sets per Year
Contact Now
Detailed Product Description
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Core Components: PLC, Bearing, Gearbox, Motor, Pump Type: Pipe Mill
Pipe Material: Carbon Steel Application: Energy Supply Pipe
Production Capacity: 50 Tons/8 Hours Voltage: 220V/380V/415V/440V
Power(w): According To Machine Model Dimension(L*W*H): 50m*6m*2.8m
Weight: 34 Kg Warranty: One Year
Key Selling Points: Easy To Operate After Sales Service Provided: Engineers Available To Service Machinery Overseas
Place Of Original: Jiangsu China Mainland Color: As Per Customer Request
After Warranty Service: Field Maintenance And Repair Service Local Service Location: None
Showroom Location: None Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year Condition: New
Applicable Industries: Building Material Shops, Manufacturing Plant, Construction Industry

Field Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making Machinery

Model

Tube O.D.

(mm)

Thickness

(mm)

Square&Rectangle

(mm)

Thickness

(mm)

Speed

(M/min)

ZG16 Φ8~Φ25mm δ0.3~1.0 10×10~20×20 δ0.3~0.8 30~120M/min
ZG25 Φ8~Φ32mm δ0.4~1.3 10×10~25×25 δ0.3~1.0 30~110M/min
ZG32 Φ13~Φ40mm δ0.5~1.8 10×10~30×30 δ0.4~1.4 30~100M/min
ZG45 Φ16~Φ50.8mm δ0.6~2.3 12×12~40×40 δ0.6~1.6 30~100M/min
ZG50 Φ19~Φ63.5mm δ0.7~2.75 15×15~50×50 δ0.7~2.3 30~100M/min

ZG50

(Enlarge to 76)

Φ19~Φ76mm δ0.7~2.75 15×15~60×60 δ0.7~2.3 30~100M/min
ZG60 Φ19~Φ63.5mm δ0.8~3.5 15×15~50×50 δ0.8~2.75 30~90M/min

ZG60

(Enlarge)

Φ19~Φ76mm δ1.0~3.0 15×15~60×60 δ1.0~2.5 30~80M/min

ZG60

(Enlarge to 102)

Φ22~Φ102mm δ1.0~3.0 16×16~80×80 δ1.0~2.5 20~80M/min
ZG76 Φ25~Φ90mm δ1.0~4.0 200×20~70×70 δ1.0~3.5 30~70M/min

ZG76

(Enlarge to 127)

Φ32~Φ127mm δ1.2~4.0 25×25~100×100 δ1.2~3.0 30~70M/min
ZG90 Φ32~Φ127mm δ1.5~4.5 25×25~100×100 δ1.5~3.75 20~60M/min

ZG90

(Enlarge to 140)

Φ40~Φ140mm δ1.5~4.5 30×30~110×110 δ1.5~3.75 20~60M/min
ZG115 Φ48~Φ127mm δ1.5~5.0 40×40~100×100 δ1.5~4.0 20~60M/min

ZG115

(Enlarge to 165)

Φ60~Φ165mm δ1.5~5.0 50×50~130×130 δ1.5~4.0 20~60M/min
ZG165 Φ50.8~Φ165mm δ2.0~6.0 40×40~130×130 δ2.0~5.0 15~50M/min

ZG165

(Enlarge to 219)

Φ76~Φ219mm δ2.0~5.0 60×60~170×170 δ2.0~4.0 15~50M/min
ZG219 Φ89~Φ219mm δ2.5~8.0 70×70~170×170 δ2.5~6.0 12~35M/min
ZG273 Φ114~Φ273mm δ3.0~10.0 90×90~210×210 δ3.0~8.0 10~30M/min



Field Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making MachineryField Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making Machinery

Field Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making MachineryField Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making MachineryField Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making Machinery

Field Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making Machinery

Field Maintenance and Repair Service Nanyang Forming Welding Sizing Machine Tube Mill Pipe Making Machinery

Q: Which products your company are manufacturing?

A:Our company main products is Carbon steel/GI pipe pipe making machine and also we can make Stainless steel pipe making machine.



Q: What advantage for the machine?

A:We have Adopt first class suppliers. like "Hangzhou Xinhengli" DC Motor, "GUOMAO" Reducer, Siemens AC motor on the machine.



Q: Can you print the company name or logo on the pipes?

A: Yes. We can print your logo or company name on the pipes by Stamping or Coating.



Q: What payment terms you can accept?

A: We can accept payment terms by T/T(30% deposit, 70% before shipment),  L/C at sight



Q: When is your company delivery time?

A: For small model of machine, our delivery time is within 100 days, It depends on your machine model.



Q: How many workers will need to operate the machine?

A: 3~6 workers for one line, need one skillful stuffs for adjusting the machine rollers.



Q: How long will take to change the roller on the machine?

A: If one worker to change the roller, will need about 4~6 hours to change , But sometime is according to the worker whether have enough familiar to decide.



Q: How many tons for normal machine to production per month?

A: Our machine is according to the model to decide , under the situation, one machine can produce 1400 tons per month.





 Q: How we get from the machine for after service?

A: We will supply technical support for installation , operation and maintain etc ,Also we can arrange the technical engineer to your company .
